| Brand | MSI |
| Model | H470M-PRO |
| Chipset | Intel H470 |
| Socket | LGA 1200 |
| Supported CPUs | 10th Gen Intel Core and Pentium Gold/Celeron processors |
| Form Factor | Micro-ATX |
| Dimensions | 202mm x 236mm |
| Audio | Realtek ALC897 Codec, 7.1-Channel High Definition Audio |
| Expansion Slots | |
| PCI-E | 1x PCI-E x16 slot, 1x PCI-E x1 slot |
| PCI-E1 | Gen 3.0, supports up to x16 (From CPU) |
| PCI-E2 | Gen 3.0, supports up to x1 (From Chipset) |
| Memory | |
| Type | DDR4 |
| Slots | 2 |
| Supported Memory | 2933, 2666, 2400/ 2133 MHz |
| Dual-Channel Mode | Yes |
| Non-ECC, Un-buffered Memory | Yes |
| Graphics | |
| HDMI | 1x HDMI 1.4, supports max resolution 4K 30Hz |
| VGA | 1x VGA, supports max resolution 2048x1536 at 50 Hz and 1920x1200 at 60 Hz |
| Display Port | No |
| USB | |
| Rear | 4x USB 2.0, 2x USB 3.2 Gen1 Type-A |
| Front | 4x USB 2.0, 2x USB 3.2 Gen1 Type-A |
| Network | Realtek 8111H Gigabit LAN |
| Storage | |
| M.2 | 1x M.2_1 (From Chipset), supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| SATA | 4x SATA 6G |
| Internal I/O Ports | |
| 1x ATX Power Connector | |
| 1x CPU Power Connector | |
| 1x CPU Fan Header | |
| 2x System Fan Headers | |
| 2x Front Panel Headers (JFP) | |
| 1x Chassis Intrusion (JCI) | |
| 1x Front Audio (JAUD) | |
| 1x Com Port (JCOM) | |
| 1x RGB LED connector (JRGB) | |
| 4x USB 2.0 ports | |
| 2x USB 3.2 Gen1 Type A ports | |
| TPM | 1x TPM pin header (Support TPM 2.0) |
| Special Features | 4x EZ Debug LED |
| Warranty | 3 years |
